Power Central Lifepo4 Charger 72V 60V 48V 36V 24V 12V 10A 5A battery Charger 24S 20S 16S 12S 8S 4S

Dimensions: 175*75*45mm

Battery type: LiFePO4 battery

Working power: 100-240Vac, 50 ~ 60Hz

Suitable for Battery Voltage: 24S 20S 16S 12S 8S 4S

Output voltage: 72V 60V 48V 36V 24V 12V

Output current: 5A/10A

Use: LiFePO4

Charging mode: constant current - Constant Voltage - trickle (floating charge) three-stage intelligent charging

Charging efficiency: ≥85% (full load)

Working temperature: -5 ° ~ +40 °

Storage temperature: -40 ° ~ +70 °

AC power cord, DC connector can be customized.

Features:

1. Three-stage charging work mode - constant current, constant voltage, trickle (or float)

2. Safety design, short circuit protection, overcurrent, overvoltage automatic monitoring of current, conversion charging mode

3. High-precision current and voltage lock, to ensure fully charged, no overcharge

4. Overcurrent, overvoltage, short circuit protection, safe and reliable

5. Conversion efficiency> 90%, small size. Light weight. Efficient environmental protection

LED Light:

RED ---Charging

Green---Full charged, Stop automatically and turn green when the battery is full charged.
